TWM Series

LED Display

FINE PITCH LED DISPLAY

TWM Series LED Display

P1.25 | P1.56 | P1.875

Fine Pitch LED displays represents the top technology of LED display field, they may be used in high-end conference rooms, TV studios, the government mansion, etc. It has the smallest pixel pitch (1mm or even less) and the finest display effect. BRWall is the pioneer in the field of HD LED display, and has many successful cases already.

Key Features

16:9 chassis design

16:9 chassis design, point-to-point matching HD video source.

2D/3D Display

Support 2D/3D display at the same time, active 3D without strobe, no loss of resolution.

Low Voltage Power

low voltage power supply, natural heat dissipation, no fan, zero noise.

No Granular Effect

No granular effect, good uniformity and no mosaic phenomenon.

Point-by-point Calibration

Module-level point-by-point calibration design, power-on automatic balance correction.

Die-cast Aluminum

Integrated die-cast aluminum design, 360° all-round heat dissipation, longer life.

Dual Signal Inputs

Redundant power supply design, dual signal inputs, system’s stability and reliability.

Front Maintenance

Complete front mounting and front maintenance structure, the overall installation thickness is only 125mm.

16:9

16:9 chassis design, point-to-point matching HD video source.

Completely Front Maintenance

Cabinets and modules are separated packed, first install cabinets and then install modules.
Smart adjust: unique alignment features ensure the video wall is perfect aligned and seamless, the flatness tolerance of screen is ≤ 0.1mm.
1.The magnet edge-on the front.
2.Magnet is appressed in the middle of module.
3.Pulling the magnet slowly, module will be apart from cabinet.
4.The same way to put the module back to the cabinet.

Power Supply &
Signal Back up

Redundant power supply design, dual signal inputs, auto matically detecting the failure then switch, ensure the whole system’s stability and reliability.

Low Brightness
With High Gray Scale

BRWall LED display use high quality LED Lamps and PWM drive IC, goes with Lamp Video’s patented mask and special images arithmetic processing that makes a better color rendering, color revivification and more details even in low brightness mode. Excellent gray scale performance even in low-brightness of 100 cd/㎡.
Normal LED display Low gray scale poor performance.
BRWall LED display low brightness, high gray scale.
960Hz (Shutter Speed 2000)
3840Hz (Shutter Speed 2000)

Professional Image
With High Refresh Rate

Up to 3840Hz high refresh rate keeps it high quality display performance even under professional camera, no water waves or screen flashing, totally meet the live show requirements.

Nanosecond Level Response Time

LED response shortly in nanosecond level without smearing or double image effect.
BRWall video LED Display
Projection
TWN series enjoy a long product life (100,000 hours, 8-10years),
attributed to its advanced experience in manufacturing and processing management, rich design experience in drive circuit.

100000

Hours Lifetime

Specifications

TWM Series P1.25 P1.56 P1.875
Pixel Pitch 1.25 mm 1.56 mm 1.875 mm
Module Size (WxHxD) 300mmx112.5mmx13mm 300mmx112.5mmx13mm 300mmx112.5mmx13mm
Physical Density 640,000 Pixel/㎡ 410,900 Pixel/㎡ 284,444 Pixel/㎡
Module Resolution (W×H) 240x90 192x72 160x60
Module Port HUB-HD01 HUB-HD01 HUB-HD01
Driving Method Constant Current 1/30scan Constant Current 1/30scan Constant Current 1/32scan
LED Encapsulation Commercial Grade 3-in-1 SMD1010 (Black) Commercial Grade 3-in-1 SMD1010 (Black) Commercial Grade 3-in-1 SMD1515
Module Working Voltage 4.2-5 VDC 4.2-5 VDC 5 VDC
Module Maximum Power Consumption 35W 35W 35W
Viewing Angle (Horizontal/Vertical) 160°/140° 160°/140° 120°
Module Of Cabinet (W×H) 2x3 2x3 2x3
Cabinet Resolution (W×H) 480x270 384x216 320x180
Option Distance 1-30m 1-30m 1-30m
Frame Rate 60Hz/120Hz(3D) 60Hz/120Hz(3D) 60Hz/120Hz(3D)
Refresh Rate 1920-3840Hz Adjustable 1920-3840Hz Adjustable 1920-3840Hz Adjustable
Brightness 300-800 cd/㎡ Adjustable 800-1000 cd/㎡ Adjustable 750 cd/㎡ Adjustable
Contrast Ratio 5000:1 5000:1 5000:1
Colour Temperature 3200K-9300K 2000K-9500K 8500K-11500K
Brightness Uniformity >97% >97% >97%
Color Uniformity >97% >97% >97%
Light Pixel Centerline Spacing Difference <3% <3% <3%
Singel Pix Brightness Corretion Support Support Support
Gray Scale/color ≥16.7M color ≥16.7M color ≥16.7M color
LED Lifetime: Typical 100,000 hrs 100,000 hrs 100,000 hrs
Cabinet Weight 4.8Kg 4.8Kg 4.8Kg
Cabinet Flatness ≤0.1mm ≤0.1mm ≤0.1mm
Cabinet Size (WxHxD) 600mmx337.5mmx80mm 600mmx337.5mmx80mm 600mmx337.5mmx80mm
Maximum Power 280 W 240 W 180 W
Display Working Voltage 100-240VAC 50/60Hz 100-240VAC 50/60Hz 100-240VAC 50/60Hz
Working environment temperature -10~40℃ -10~40℃ -10~40℃
Working Environment Humidity(RH) 10%~70% 10%~70% 10%~70%
