Double-sided Display

1.98cm Ultra-thin Series

Powerful video and image display devices.

Double-sided Digital Signage

1.98cm Ultra-thin Design.

Real point-to-point 4K display, clear picture, better performance.

178°viewing angle.

Hanging installation, installation height can be adjusted freely, simple and convenient.

Higher brightness, 350-700cd/㎡ screen brightness.

Service life up to 50,000 hours.

Support both sides of same or different.

Self contained information release system can be controlled remotely.


1.98cm Ultra-thin Series


Floor-standing
Double-sided Digital Signage


Hanging-up
Double-sided Digital Signage


Light Box Advertising
Double-sided Digital Signage


43" Hanging-up
Double-sided Digital signage

Packing: Carton and Pearl Wool
Packing Size: L137cm*W14cm*H81cm
Gross Weight: 24KG

55" Hanging-up
Double-sided Digital signage

Packing: Carton and Pearl Wool
Packing Size: L165cm*W15cm*H95cm
Gross Weight: 33KG

43" Hanging-up
Double-sided Digital signage

Packing: Carton and Pearl Wool
Packing Size: L81cm*W14cm*H137cm
Gross Weight: 24KG

55" Hanging-up
Double-sided Digital signage

Packing: Carton and Pearl Wool
Packing Size: L95cm*W15cm*H165cm
Gross Weight: 33KG

55" Light Box Advertising
Double-sided Digital Signage

Packing: Carton and Pearl Wool
Packing Size: L95cm*W15cm*H165cm
Gross Weight: 33KG

55" Floor-standing
Double-sided Digital Signage

Packing: Carton and Pearl Wool
Packing Size: L95cm*W15cm*H165cm
Gross Weight: 33KG

Specifications

Size 43inch / 55inch
Proportion 16:9
Resolution 3840*2160~1920*1080
Types Of TFT-LCD+LED backlight
Viewing Angle Landscape 178 portrait 178
Brightness 350-700cd/㎡
Enter HDMI inerface×1 / USB interface×2 / TF card slot×1 LAN Ethernet interface×1
Output Display signal×2(two-way double-sided display) infrarde receiver(remote control)
Audio output(left and roght channel output 8W×2 sppeaker
Hardware Parameter CPU:Rockchip RK3288 superstrong quad core 1.8GHz Cortex-A17 architecture,quad-core GPU Mail-T764 Memory:DDR3 2G Storage EMMC 8G (Android 5.1)
Play Format Video:Support wmv,avi,rm,rmvb,flv,mpeg,ts,etc,mp4. Image format support BMP,PNG,GIF,JPEG
Play mode supports multiple play modes such as loop,timing,and insert
Network Support RJ45 wirde network interface,3G,support Wifi / BT,4G function(optional)
  RTC real-time clock support time switch machine extended sata hard disk
Power Supply Working power supply:AC100-240V 50/60Hz
Power 110W / 145W
Surroundings Temperature:0-50 degrees Humidity:10%-90%
